Ductile Iron Grooved Mechanical Tee

PRODUCT SPECIFICATION
Main Run Size Range: 50 NB to 300 NB (2" to 12")
Branch Outlet Size: 32 NB to 200 NB (1-1/4" to 8")
Housing Material: Ductile Iron (ASTM A536, Grade 65-45-12)
Outlet Type: Grooved End (to suit standard couplings)
Gasket Material: EPDM (Grade ‘E’) - Pressure responsive
Working Pressure: 300 PSI (20.7 Bar)
Hardware: Carbon Steel Track Bolts & Nuts (Zinc Plated)
Surface Finish: Red Epoxy Powder Coated (RAL 3000)
Required Hole Prep: Clean-cut hole using a mechanical hole saw
Certifications: UL Listed, FM Approved, and VdS​

DESCRIPTION

The DI Grooved Mechanical Tee is a two-piece "saddle" fitting used to create a 90-degree branch outlet on an existing pipe without the need for cutting or welding. After drilling a hole in the main pipe, the two halves of the housing are bolted around it. The branch outlet is grooved, making it compatible with any standard grooved coupling. This is the industry-standard solution for adding large branch lines in fire protection risers, HVAC chilled water systems, and industrial process lines.​
